Motor Stamping: High-Precision Lamination for Drone & BLDC Propulsion Systems

Reenives: Leading Drone Motor Stamping Supplier in China — complete stamping solutions for stator and rotor laminations with burr ≤0.025mm, ultra-low core loss, and C5 epoxy coating, optimized for UAV, robot, and industrial BLDC motors.

📖 Article Contents – Engineer’s Guide to Motor Stamping

1. What is Motor Stamping?
2. Classification of Motor Laminations
3. Technical Parameters & Lab Data
4. Key Applications (Drone / Robot / Servo)
5. 5-Step Motor Stamping Selection Process
6. FAQs – Stamping & Lamination Core Questions
7. Summary & Contact Reenives
8. Dongguan Runlu Motor Technology Co., Ltd.

⚙️ What Is Motor Stamping?

Motor stamping refers to the high-speed precision punching of electrical steel sheets into stator and rotor laminations, which are then stacked to form the magnetic cores of brushless DC motors. For drone propulsion systems, motor stamping quality directly impacts torque density, efficiency, thermal performance, and high-speed stability. Reenives utilizes progressive dies with ultra-tight clearances (0.008-0.012mm per side) to produce laminations with consistent magnetic orientation and minimal burr, essential for 12N14P, 24N28P UAV motor architectures and industrial servos.

🖼️ [Image: High-speed progressive stamping press for motor laminations – 350SPM, automated stacking. Reenives smart factory.]

🏷️ Types of Motor Stamping Laminations

As a specialized motor stamping supplier, Reenives manufactures a full range of lamination configurations:

One-piece stator lamination: Integrated ring design for high-volume mass production (racing drone motors, e-scooters).
Split-teeth segmented stator: Individual tooth segments allowing higher copper fill factor (>45%) – ideal for heavy-lift UAVs and robot joints.
Surface-mounted magnet rotor laminations (SPM): For outrunner drone motors, with precise magnet pocket geometry.
Interior permanent magnet rotor (IPM): For high-torque servo drives and automotive BLDC.
Salient-pole rotor stampings: For switched reluctance and specialized designs.
Coating options: C3 phosphate (standard) or C5 epoxy powder coating for corrosion and insulation resistance.

📊 Critical Motor Stamping Parameters + Third-Party Data (IEC / ASTM)

Reenives maintains ISO 9001:2025 certified stamping processes. Below are typical specifications for drone motor laminations (0.27mm 35WW270 electrical steel):

Parameter	Value Range	Test Standard / Source
Material thickness (after stamping)	0.20 / 0.27 / 0.35 mm (±0.005mm)	Micrometer, ASTM A34
Burr height (max)	≤ 0.025 mm (Grade S1)	VDE 0660-2, optical measurement
Core loss @ 400Hz / 1.0T	≤ 9.2 W/kg	Epstein frame (IEC 60404-2)
Stacking factor	≥ 97.2%	Weight/volume per JIS C 2550
Concentricity (OD/ID) – rotor/stator	≤ 0.025 mm	CMM, Reenives QA
Coating insulation resistance (C5 epoxy)	> 50 Ω·cm²	Franklin tester (ASTM A717)

Data source: Reenives in-house lab & SGS certified batch reports (2024). Custom stamping for high-frequency >1kHz also available.

🚁 Drone Propulsion, Robotics & Industrial BLDC Applications

Our motor stampings power motion systems across industries:

Drone propulsion motors (outrunner & inrunner): FPV racing (2207, 2306), agricultural UAVs (40mm+ stator OD), eVTOL thrust units.
Robot joint motors (cobots & AGVs): Low-cogging IPM rotors and segmented stators for smooth torque.
Industrial servo motors: High-dynamic response for CNC, automation, and packaging machinery.
Automotive BLDC actuators: EPS motors, cooling fans, oil pump stators/rotors.
Medical robotic systems: Ultra-precision laminations with minimal imbalance and low audible noise.

🖼️ [Application Image: Reenives stator and rotor laminations assembled into a 12-inch agricultural drone motor – thermal imaging shows uniform temperature distribution at 80A continuous.]

✅ 5-Step Engineering Selection Guide for Motor Stamping

Step 1: Define motor type & operating frequency
High-speed drone motors (>30k RPM) require thinner stampings (0.20mm). Robot joints (low RPM high torque) use 0.35mm for cost efficiency.

Step 2: Specify stator & rotor geometry
Provide 2D/3D drawings. Reenives engineers simulate stamping feasibility, strip layout, and material utilization.

Step 3: Choose electrical steel grade
Standard: 50WW800 (general), 35WW270 (high efficiency), 20JNEH1200 (high-strength for drone). Full material cert provided.

Step 4: Select coating & insulation
C5 epoxy coating recommended for agricultural drones and outdoor robots (240h salt spray tested). C3 for indoor industrial servos.

Step 5: Request sample stampings & validation
Free engineering samples (≤100 pcs stator + rotor) with core loss, burr, and concentricity report. Lead time: 12-18 days for prototype stamping.

❓ FAQ – Technical Questions About Motor Stamping & Lamination Performance

1. What is the maximum burr height allowed for drone motor stator/rotor stampings to avoid performance loss?

Answer: Reenives guarantees burr height ≤0.025mm (Grade S1 per VDE 0660-2). Higher burr increases inter-laminar short circuits and eddy current loss, reducing motor efficiency. Source: Parameter table – burr height specification.

2. Can you stamp both stator and rotor laminations from the same electrical steel coil?

Answer: Yes. Reenives offers nested stamping solutions that produce matched stator and rotor laminations from the same material batch, ensuring consistent magnetic properties and reducing scrap. Source: Motor stamping process description.

3. How does C5 epoxy coating benefit motor stampings for drone propulsion?

Answer: C5 epoxy provides inter-laminar insulation resistance >50 Ω·cm² and passes 240h salt spray test, preventing rust in humid/dusty environments and reducing eddy current loss at high frequency. Source: Coating insulation resistance & C5 description.

4. What stacking factor can you achieve for high-efficiency BLDC motor laminations?

Answer: Our progressive stamping maintains stacking factor ≥97.2% (JIS C 2550), meaning more active magnetic steel per stack height, improving torque density and power output. Source: Parameter table – stacking factor.

5. Do you provide stress-relief annealing after stamping to restore magnetic properties?

Answer: Yes, optional annealing service is available to reduce residual stress from stamping, limiting core loss increase to ≤2% vs raw material. Standard stamping keeps increase ≤5% (acceptable for most drone motors). Source: Core loss deviation & additional service note.
