BLDC Motor Stator and Rotor Lamination Supplier
BLDC Motor Stator and Rotor — Matched Lamination Cores for Drone & Brushless Motors | Reenives Stator Core Supplier
⚠️ Are your BLDC motor stator and rotor laminations mismatched, causing high core loss, vibration, or torque ripple? Inconsistent lamination thickness, burrs, weak interlocking, or a poorly matched air gap can reduce motor efficiency, generate excess heat, and shorten flight time — especially in high-RPM drone brushless motors.
✅ Reenives is a BLDC motor stator and rotor lamination supplier producing matched cores engineered for drone brushless motors. With imported high-speed stamping lines, epoxy powder coating, and dust-free workshops, we deliver stator and rotor laminations with low core loss, tight tolerances, and consistent stacking. As a reliable BLDC motor stator and rotor lamination supplier, we help 1000+ enterprises improve motor performance and reliability.
📋 Table of Contents
What Are BLDC Motor Stator and Rotor Laminations?
BLDC motor stator and rotor laminations are thin sheets of electrical steel (silicon steel) stamped into precise core shapes and stacked to form the stationary stator core and the rotating rotor core of a brushless DC motor. Each lamination is coated with a thin insulation layer to limit eddy currents between layers — essential for efficient high-frequency operation.
In drone brushless motors, the stator and rotor laminations are the foundation of the electromagnetic circuit. Their material grade, thickness, stamping quality, and coating directly determine:
- Core loss & motor efficiency
- Stacking factor & magnetic flux density
- Air gap consistency & vibration levels
- Torque density & thermal performance
Because the stator and rotor form a single magnetic circuit, they must be designed and manufactured as a matched pair. Stamping both cores from the same material and to the same tolerance ensures the air gap remains uniform around the circumference — critical for smooth rotation at high RPM.
Matched BLDC motor stator and rotor laminations — manufactured by Reenives with imported high-speed stamping & epoxy powder coating lines.
Types of Stator & Rotor Laminations
Stator and rotor laminations come in different designs and materials, each suited to specific BLDC motor requirements. Reenives manufactures the following types:
- One-Piece Stator Laminations — Traditional full-ring lamination design, cost-effective for medium to high-volume production.
- Segmented Stator Laminations — Individual teeth stamped separately for separate winding, then assembled into a full core. Higher slot fill factor.
- Rotor Laminations with Magnet Pockets — Rotor laminations stamped with surface-mount or interior magnet slots for IPM designs.
- Bonded Laminations — Laminations coated with adhesive and bonded under heat and pressure, reducing eddy current losses and vibration.
- Interlocked Laminations — Laminations with integral interlocking features (e.g., dimples or dovetails) for mechanical assembly without adhesive.
- Epoxy-Coated Laminations — Individually coated with epoxy powder for superior insulation, corrosion resistance, and wire adhesion.
- Laser-Cut Laminations — No tooling cost, fast turnaround for prototypes and low-volume production.
- Custom Laminations — Private mould development for unique slot counts, outer diameters, and tooth profiles.
Whether you need standard 0.20 mm laminations for high-RPM drone motors or 0.50 mm for cost-sensitive designs, Reenives can supply the right solution.
Key Specifications & Data
Below are typical specifications for Reenives BLDC motor stator and rotor laminations. Custom values are available upon request.
| Parameter | Typical Range / Value | Notes |
|---|---|---|
| Lamination Material | Silicon steel (e.g., 35WW250, 50WW470) | Low core loss grades |
| Lamination Thickness | 0.20 mm – 0.50 mm | Thinner = lower eddy current loss |
| Stator Outer Diameter | 20 mm – 200 mm | Customizable |
| Stator Bore (Inner Diameter) | 10 mm – 180 mm | Depends on rotor design |
| Rotor Outer Diameter | 10 mm – 180 mm | Matched to stator bore |
| Stack Length | 5 mm – 80 mm | Affects torque & power |
| Slot / Pole Number | 6S/4P, 9S/6P, 12S/14P, 24S/28P | Matched pairs |
| Air Gap | 0.2 mm – 1.0 mm | Affects efficiency & cogging |
| Insulation Coating | Epoxy powder coating | Uniform, pinhole-free |
| Core Loss (at 400Hz, 1T) | ≤ 25 W/kg | Material dependent |
| Tolerance | ±0.05 mm (critical dimensions) | High-precision stamping |
| Burr Height | ≤ 0.03 mm | Clean edges for stacking |
| Stacking Factor | ≥ 95% | Minimizes air gaps |
Data source: Reenives internal testing & supplier material datasheets, 2024. Actual values may vary by design.
Applications of BLDC Motor Stator & Rotor Laminations
Reenives BLDC motor stator and rotor laminations are used across a wide range of drone and brushless motor applications:
- FPV Racing Drones — High RPM, lightweight laminations with low cogging torque and low inertia.
- Cinematic & Photography Drones — Smooth, vibration-free laminations for stable aerial footage.
- Agricultural Spraying Drones — Corrosion-resistant epoxy-coated laminations for harsh chemical environments.
- Industrial Inspection Drones — High-torque laminations for long endurance and heavy payloads.
- eVTOL & UAV Propulsion — Custom high-power laminations for next-generation air mobility.
- Robot Actuators — Low cogging torque laminations for precise motion control.
- EPS Motors — Low NVH laminations for automotive electric power steering systems.
- General BLDC Motors — Fans, pumps, power tools, and automotive actuators.
Reenives BLDC motor stator and rotor laminations power FPV, agricultural, cinematic, and industrial UAVs worldwide.
How to Select the Right BLDC Stator & Rotor Laminations
Choosing the correct stator and rotor laminations for your BLDC motor involves several engineering decisions. Follow these steps:
- Determine Required Torque & RPM — Higher torque needs more stack length or larger diameter. High RPM demands thinner laminations and low-loss material.
- Select Slot/Pole Combination — Common drone motors use 12S/14P or 9S/6P. This must be matched between stator and rotor.
- Choose Lamination Thickness — For high-frequency operation (e.g., 400Hz+), use 0.20 mm laminations to reduce eddy current losses.
- Select Material Grade — Lower-loss silicon steel grades (e.g., 35WW250) reduce heat but cost more. Balance performance and budget.
- Design the Air Gap — The gap between stator bore and rotor outer diameter must be small enough for efficiency but large enough for mechanical clearance.
- Decide on Assembly Method — Interlocked, bonded, or segmented laminations each have trade-offs in cost, NVH, and performance.
- Consider Insulation & Coating — Epoxy powder coating is recommended for moisture, vibration, and chemical resistance.
- Request Samples & Test — Reenives provides free samples for qualified projects. Test core loss, cogging torque, temperature rise, and mechanical fit.
FAQ — BLDC Stator & Rotor Lamination Parameters
Q1: Why must the BLDC stator and rotor laminations be bought as a matched pair?
A: The stator and rotor form a single magnetic circuit. If they are not matched — wrong air gap, mismatched slot/pole count, or different thermal expansion — the motor can suffer from high cogging torque, reduced efficiency, vibration, and premature bearing wear. Buying a matched pair from a single supplier ensures the air gap, tolerances, and magnetic design are optimized together. Our high-precision stamping ensures stator bore and rotor outer diameter tolerances of ±0.05 mm, allowing reliable small air gaps.
Source: Reenives engineering team, based on motor design principles.
Q2: What lamination thickness do you recommend for high-RPM BLDC drone motors?
A: For high-RPM BLDC drone motors (above 10,000 RPM), we recommend 0.20 mm or 0.25 mm silicon steel laminations for both stator and rotor. Thinner laminations significantly reduce eddy current losses, which helps keep the motor cool and improves efficiency. For lower RPM applications, 0.35 mm or 0.50 mm can be more cost-effective.
Source: Reenives engineering team, based on motor design guidelines and material datasheets.
Q3: What is the typical core loss of your BLDC stator and rotor laminations?
A: Our standard BLDC stator and rotor laminations using 35WW250 silicon steel typically exhibit core loss ≤ 25 W/kg at 400Hz and 1 Tesla. With premium low-loss materials, we can achieve even lower values. Actual core loss depends on lamination thickness, material grade, and operating frequency.
Source: Reenives internal testing data, 2024.
Q4: What is the dimensional tolerance and burr height of your stator and rotor laminations?
A: For critical dimensions such as inner diameter, outer diameter, and slot dimensions, we maintain tolerances of ±0.05 mm. Burr height is controlled to ≤ 0.03 mm to ensure clean stacking and reduce vibration. Tighter tolerances can be achieved upon request with our high-precision stamping lines.
Source: Reenives quality control standards.
Q5: Do you offer epoxy powder coating for BLDC stator and rotor laminations?
A: Yes. We use imported epoxy powder coating equipment to apply a uniform, pinhole-free insulation layer on individual stator and rotor laminations before stacking. This coating improves corrosion resistance, enhances wire adhesion, and protects against moisture — critical for agricultural and marine drones.
Source: Reenives production specification.
Q6: Can you develop custom BLDC stator and rotor laminations for my specific drone motor?
A: Absolutely. We support private mould development. Provide us with your required stator outer diameter, stator bore, rotor outer diameter, stack length, slot/pole combination, and magnet configuration. Our R&D team will design and produce custom laminations tailored to your motor. Tooling lead time is typically 15–25 days.
Source: Reenives custom development process.
Summary — Get Your BLDC Stator & Rotor Lamination Quote Today
Ready to Improve Your BLDC Motor Performance with Matched Stator & Rotor Laminations?
Reenives is a reliable BLDC motor stator and rotor lamination supplier with 4 years of manufacturing experience, 100+ R&D patents, and 3 production bases. We serve 1000+ enterprises worldwide with high-precision stator and rotor laminations for UAV and BLDC motors.
📦 Bulk purchasing · 🔧 Private mould development · 🧪 Free samples
🌐 Official Website: www.reenives-bldcmotor.com
📧 Email: linda_reenives@163.com
Contact us now for a free sample and tailored solution for your production scenario.
Dongguan Runlu Motor Technology Co., Ltd.
Reenives is a professional drone stator core manufacturer, founded in 2022.
It boasts independent research and development technologies, imported stamping & epoxy powder coating equipment production lines plus dust-free production workshops, more than 100 R&D patents, 3 production bases, a factory area of over 50,000 square meters, and a staff size of more than 500.
From production to sales, we support bulk purchasing, private mould develop, and samples making, and can provide tailor-made perfect solutions for your production and usage scenarios. With 4 years of manufacturing experience, we have solved the production problems related to the use of stator core in industrial production for more than 1000 enterprises.
We can ship globally (with complete export qualifications). Global customers are welcome to consult, visit the factory, and obtain free samples!
