700KV 3508 BLDC Motor – High-Torque Stator Cores for Heavy-Lift Drone & UAV Propulsion
Heavy-lift drone performance limited by motor torque? Need reliable 3508 stator cores for your hexacopter or octocopter? The 700KV 3508 BLDC motor is a high-torque outrunner designed for heavy-lift drones, hexacopters, octocopters, and UAV applications requiring exceptional thrust and reliability. As a specialist 700KV 3508 BLDC motor stator lamination supplier, Reenives delivers precision 12N14P stator cores with 0.2mm ultra-thin silicon steel, burr height < 0.03mm, and epoxy coating—optimized for 700KV operation with 13–15 inch propellers, delivering up to 1.5kg+ thrust per motor and reliable performance for heavy-lift UAV platforms.
- • What Is a 700KV 3508 BLDC Motor?
- • Classification of 3508 700KV Stator Cores
- • Technical Specifications & Verified Data
- • Applications: Heavy-Lift Drones, Hexacopters, Octocopters & More
- • 6-Step Engineering Selection Guide for 3508 700KV Stators
- • FAQ: 700KV 3508 BLDC Motor Technical Questions
- • Why Reenives – 700KV 3508 BLDC Motor Stator Lamination Supplier
- • Dongguan Runlu Motor Technology Co., Ltd.
What Is a 700KV 3508 BLDC Motor?
A 700KV 3508 BLDC motor is a brushless outrunner motor with a 35mm stator diameter, 8mm stator height, and a KV rating of 700 RPM per volt. This combination delivers exceptional torque and thrust, making it ideal for heavy-lift drones, hexacopters, octocopters, and UAV applications requiring reliable performance with large propellers.
Understanding the 700KV 3508 designation:
- 35mm stator diameter – A large stator for high-torque, heavy-lift applications
- 8mm stator height – Provides strong torque output for large propellers
- 700KV rating – 700 RPM per volt; on 4S (14.8V), spins at approximately 10,360 RPM unloaded
- Outrunner configuration – Rotor on the outside, delivering high torque for direct-drive propellers
- Typical applications – Heavy-lift hexacopters, octocopters, UAVs, professional drones
- Propeller compatibility – 13–15 inch propellers for maximum thrust
ⓘ 3508 700KV insight: "The 700KV 3508 BLDC motor is a trusted workhorse for heavy-lift drone applications, delivering exceptional thrust and reliability for professional UAV platforms."
Reenives manufactures precision stator cores for 700KV 3508 BLDC motors using imported 0.2mm silicon steel, progressive stamping dies, and automated epoxy powder coating—delivering optimal torque performance for heavy-lift drones, hexacopters, and octocopter applications.
Classification of 3508 700KV Stator Cores
Reenives supplies 3508 700KV stator cores across three primary series, tailored to different heavy-lift applications:
| Series | Stator Size (mm) | KV Rating | Recommended Propeller | Cell Compatibility | Lamination Thickness | Best For |
|---|---|---|---|---|---|---|
| Series A – Hexacopter | 35x8mm | 700KV | 13–14 inch | 4S–6S | 0.20mm | Hexacopter platforms, balanced thrust |
| Series B – Heavy-Lift / Octocopter | 35x8mm | 700KV | 14–15 inch | 4S–6S | 0.20mm | Heavy-lift octocopters, maximum payload |
| Series C – Custom OEM | 35x8mm | 700KV | Custom | Custom | 0.15–0.35mm | Specialized designs, proprietary motors |
3508 700KV stator cores are optimized for heavy-lift applications:
- 700KV: High torque output—ideal for 13–15 inch propellers
- 12N14P configuration: Standard for 3508 motors, delivering smooth torque and reliable performance
- 4S–6S battery compatibility: Flexible power options for different UAV configurations
Technical Specifications & Verified Data
All performance data below is derived from Reenives in-house laboratory testing (IEC 60404-2), third-party validation, and industry standards for 3508 700KV stator cores.
| Parameter | Value / Range (Reenives Standard) | Test Standard / Source |
|---|---|---|
| KV Rating Compatibility | 700KV (torque-optimized) | Industry standard |
| Configuration | 12N14P (12 slots, 14 poles) | Reenives design standards |
| Stator Outer Diameter | 35mm | CMM / optical comparator |
| Stator Height | 8mm | Micrometer |
| Material Type | Silicon steel (CRNGO / Non-oriented) | Material certificates / IEC 60404 |
| Common Grades | 35PN210, 35PN250 (Nippon Steel / Baowu) | Material certificates |
| Lamination Thickness | 0.20mm (standard) | Micrometer / IEC 60404-2 |
| Core Loss @ 1.0T, 400Hz (0.20mm) | ≤ 8.5 W/kg — 30% lower than 0.35mm | IEC 60404-2 / Reenives R&D |
| Saturation Flux Density Bs | 1.68 – 1.72 T | Epstein frame test |
| Burr Height (max) | < 0.03mm | Optical measurement |
| Epoxy Coating Thickness | 30–60 µm, dielectric > 2.5 kV | ASTM D149 |
| Stacking Factor | ≥ 97.5% | Weight method |
| Concentricity Tolerance | ±0.01mm – ±0.015mm | CMM measurement |
| Typical Motor Efficiency | 85–90% (with optimized 700KV stator) | Industry benchmarks |
| Max Thrust (1045 prop, 4S) | 1.5kg+ per motor | Industry specifications |
🔬 Data Source: Reenives R&D Report 2024-Q4 + IEC 60404-2 standard + Material certificates + Industry benchmarks.
Applications: Heavy-Lift Drones, Hexacopters, Octocopters & More
700KV 3508 BLDC motor stator cores power a wide range of heavy-lift applications:
| Application | Typical Configuration | Propeller | Battery | Performance Priorities |
|---|---|---|---|---|
| Hexacopters | 6-motor setup | 13–14 inch | 4S–6S | Balanced thrust, reliability, endurance |
| Octocopters | 8-motor setup | 14–15 inch | 4S–6S | Maximum payload, redundancy, safety |
| Heavy-Lift UAVs | 4–8 motors | 13–15 inch | 4S–6S | High thrust, reliability, payload capacity |
| Professional Drones | Various | 13–14 inch | 4S–6S | Reliability, performance, endurance |
| Agricultural UAVs | 4–8 motors | 14–15 inch | 4S–6S | Heavy payload, durability, corrosion resistance |
"The 700KV 3508 BLDC motor is a trusted workhorse for heavy-lift drone applications, delivering exceptional thrust and reliability for professional UAV platforms."
6-Step Engineering Selection Guide for 3508 700KV Stators
For procurement engineers and motor designers, selecting the optimal 700KV 3508 BLDC motor stator core requires systematic evaluation. Here is a practical 6-step framework:
- Define UAV Application & Performance Requirements – Identify your drone's mission profile:
- Hexacopter: Balanced performance, 13–14 inch props
- Octocopter: Maximum payload, 14–15 inch props
- Heavy-lift UAV: High thrust, 13–15 inch props
- Agricultural UAV: Corrosion resistance, 14–15 inch props
- Confirm 35x8mm Stator Size – The 3508 form factor:
- 35mm diameter – Large stator for high torque
- 8mm height – Optimized for heavy-lift applications
- Choose Lamination Thickness – Thinner laminations reduce core loss:
- 0.20mm: Optimal balance—most 700KV applications
- 0.35mm: Not recommended for high-performance 3508 700KV motors
ⓘ "0.20mm laminations reduce core loss by approximately 30% compared to 0.35mm—critical for 3508 700KV motor efficiency and extended flight times."
- Confirm 12N14P Configuration – This is the standard for 3508 motors:
- 12 slots (stator teeth) with concentrated windings
- 14 poles (rotor magnets) for optimal torque output
- Smooth torque, reliable operation for heavy-lift applications
- Specify Insulation & Coating – Critical for heavy-lift reliability:
- Epoxy powder coating (30–60µm, Class H 180°C)
- Corrosion resistance for outdoor and agricultural applications
- Dielectric strength > 2.5 kV for reliable insulation
- Choose a Specialist 3508 700KV Stator Supplier – Evaluate heavy-lift motor expertise:
- Experience with 3508 700KV stator design for heavy-lift UAV applications
- Precision stamping: burr < 0.03mm, concentricity ±0.01mm
- Epoxy coating capability for heavy-lift motor environments
- Material certificates and third-party test reports
- Proven track record with 3508 motor manufacturers
- Engineering support for 3508 700KV motor optimization
FAQ: 700KV 3508 BLDC Motor Technical Questions
A 700KV 3508 BLDC motor has a stator diameter of 35mm, a stator height of 8mm, and a KV rating of 700 RPM per volt. This combination delivers exceptional torque and thrust for heavy-lift drones, hexacopters, octocopters, and UAV applications. The 3508 designation indicates the stator size, which determines the motor's power output and torque characteristics. The 700KV rating makes it ideal for 13–15 inch propellers on 4S–6S battery systems.
For 700KV 3508 BLDC motors, the optimal stator lamination features: 0.20mm silicon steel, 12N14P slot/pole configuration, burr height < 0.03mm, epoxy coating (30–60µm, Class H 180°C), and stacking factor ≥ 97.5%. The 12N14P configuration delivers smooth torque and reliable performance for heavy-lift applications. With optimized stator design, 3508 700KV motors can achieve 85–90% efficiency.
The optimal propeller for a 700KV 3508 BLDC motor depends on the battery and application: (1) 13–14 inch propellers on 4S–6S for hexacopter and general heavy-lift applications, (2) 14–15 inch propellers on 4S–6S for octocopter and maximum payload applications, (3) 13 inch propellers on 6S for high-efficiency setups. Always check the motor's specified maximum current before selecting a propeller.
700KV 3508 BLDC motors typically operate on 4S–6S LiPo batteries: (1) 4S – balanced performance for general heavy-lift applications, (2) 5S – increased power for heavier payloads, (3) 6S – maximum thrust and performance for heavy-lift octocopters and professional UAVs. Always check the motor's specified voltage range and maximum current before selecting a battery.
Epoxy powder coating provides three critical functions for 3508 700KV motor stators: (1) electrical insulation between laminations to minimize eddy currents and prevent interlaminar shorts, (2) thermal durability up to 180°C (Class H) to withstand the heat generated during sustained heavy-lift operation, and (3) corrosion resistance for operation in outdoor and agricultural environments. The coating thickness (30–60µm) is optimized with dielectric strength exceeding 2.5 kV.
700KV 3508 BLDC motors are used in: hexacopter UAV platforms (6-motor setups), octocopter UAV platforms (8-motor setups), heavy-lift professional drones, agricultural UAVs, surveying and mapping drones, and industrial inspection drones. The 3508 700KV combination is a trusted workhorse for heavy-lift applications where exceptional thrust and reliability are essential.
Why Reenives – 700KV 3508 BLDC Motor Stator Lamination Supplier
Reenives has earned its reputation as a specialist 700KV 3508 BLDC Motor Stator Lamination Supplier by combining advanced manufacturing technology with deep expertise in heavy-lift motor design.
Our Advantages — 3508 700KV Stator Specialists
- ✅ 3508 700KV Expertise: 35x8mm stator—exceptional torque and reliability for heavy-lift UAV applications
- ✅ Ultra-Thin Silicon Steel: 0.20mm laminations reduce core loss by up to 30%—critical for 700KV efficiency
- ✅ Precision Progressive Stamping: Burr height < 0.03mm, concentricity ±0.01mm, stacking factor ≥ 97.5%
- ✅ 12N14P Expertise: Standard configuration for 3508 motors—smooth torque, reliable performance
- ✅ Heavy-Lift Optimized: Designed for 13–15 inch propellers, 4S–6S battery systems
- ✅ Full Customization: Private mould development and custom specifications available
- ✅ Epoxy Coating: 30–60µm, Class H 180°C, dielectric > 2.5 kV
- ✅ Trusted Quality Control: IEC 60404-2 testing, third-party verification, and material certificates
- ✅ Global Export Capability: Complete export qualifications with worldwide shipping to UAV manufacturers
- ✅ Proven Track Record: 4 years experience, 1,000+ enterprise clients, 100+ R&D patents
🚁 Our 3508 700KV promise: Stator cores that deliver exceptional thrust and reliability for heavy-lift UAV applications. Consistent quality that eliminates rework. Engineering support that optimizes your heavy-lift motor design. That's why Reenives is the trusted 700KV 3508 BLDC motor stator lamination supplier.
🚁 Ready to power your heavy-lift UAVs with 3508 700KV precision stator cores?
Contact Reenives today for engineering consultation, OEM samples, and competitive global pricing.
